A simple Arduino IPS TFT 1.54″ Medium Brightness, IPS Mode, Transmissive, All Viewing Direction with 320 x 320 dots, 4-wire SPI Interface. Operating Temp: -20°C to 70°CStorage Temp: -30°C to 80°C, Driver IC ST7789V. It is Suitable for smart wear, smartwatch, industry, home appliances, toys, medical treatment, etc.
No. | Item | Specification |
1 | LCD size | 1.54 inch |
2 | Resolution | 320×320 |
3 | Active area | 27.74(W)×27.74(H)mm |
4 | Module size | 31.52(W)×33.72(H)×1.45(T)(Exclude FPC)mm |
5 | Interface | SPI |
6 | Brightness | 300cd/m² |
7 | Contrast Ratio | 900:1 |
8 | Driver IC | ST7789V |
9 | Viewing Direction | All |
10 | Back Light | White |
| 11 | Polarizer | Transmissive |
12 | Display mode | IPS/Normally White |
1.3 Inch 240x240 Square 13PIN 4 Wire SPI IPS 160nits TFT LCD Display Module
This single-display module is suitable for use in MB products .The LCD adopts one backlight with High brightness 2-lamps white LED. Construction: 1.3〞a-Si color TFT-LCD ,White LED backlight, FPC.
2.47 Inch 480x480 Round 35PIN MIPI 400nits TFT LCD Display
EX02403-A01 is a color active matrix TFT-LCD Panel using amorphous silicon TFT's (Thin Film Transistors) as an active switching devices. This model is composed of a TFT-LCD Panel, a driving circui...
1.44 Inch 128x128 SQQVGA Square 4 Wire SPI TN 250nits TFT LCD Display Module
A simple Arduino TN TFT 1.44″ Medium Brightness, TN Mode, Transmissive, 12 o’clock Viewing Direction with 128 x 128 dots, 4-wire SPI Interface.Operating Temp: -20°C to 70°C,Storage Temp: -30°C to...
