7.0 Inch 1024x600 TN+Ofilm 40PIN HDMI+USB IPS 450nits Open Frame LCD

7.0 Inch 1024x600 TN+Ofilm 40PIN HDMI+USB IPS 450nits Open Frame LCD

This single-display module is suitable for use in MB products .The LCD adopts one backlight with High brightness 27-lamps white LED.Construction: 7.0 〞a-Si color TFT-LCD ,White LED backlight, FPC.

Get A Quote

General Specifications of 7.0 Inch 1024x600 TN+Ofilm 40PIN HDMI+USB IPS 450nits Open Frame

No.

Item

Specification

1

LCD size

7.0 inch

2

Resolution

1024×600

3

Active area

154.2144H) × 85.92 (V) mm

4

Module size

163.8(W)×97(H)×2.60 (D) mm

5

Interface

HDMI+USB

6

Brightness

450cd/m²

7

Contrast Ratio

800:1

8

Driver IC

EXC3132

9

Polarizer


10

Pixel arrangement

RGB-stripe

11

Viewing Direction


12

Display mode

Normally black


Outline Dimension of 7.0 Inch 1024x600 TN+Ofilm 40PIN HDMI+USB IPS 450nits Open Frame

7.0 Inch 1024x600 TN+Ofilm 40PIN HDMI+USB IPS 450nits Open Frame
